Net weight electronic weigher, with twin screw feeder, Overallproject

Net weight electronic weigher, with twin screw feeder , used for handing powdery products (i.e. corn flour, chemical powder and granular mixtures) where high output is required. Each screw is driven by an electric motor with trapezoidal belt and pulley transmission. At the end of the weighing cycle, and electropneumatic catch gate, fixed under the screws, is activated and impedes the overflow of product once the desired weight is reached. The weight bin is supported Class C3 type electronic load cells. These load cells survey the weight data to forward to the connected electronic development system.

Net weight electronic weigher, with twin screw feeder , used for handing powdery products. Used if no higt output is required because the single screw performs both the main and dribble feed phases by variating its speeds.

Dati tecnici

Technical data

Tensione di lavoro 220/440 Vac

Electrical Voltage 50/60 Hz

Potenza assorbita 4,5 Kw

Power Consumption

Consumo aria 5,5 Nl/Cycles

Air consumption

Produzione max 700

Max output

Capacità It. Min-Max 30-160

Min.-Max capacity

Risoluzione peso 10-20 gr.

Weight accuracy
